Aerial Boom Lifts

45' Articulating Boom - Skyjack

Image for reference only
Actual item may look different
Click on image for larger view

Click on above thumbnails for alternate view

Manufacturer: Skyjack

Model: SJ45AJ

Quantity:

Additional Information

Height: 8 ft 2.4 in
Length: 8 ft 2.4 in
Width: 5 ft 10.9 in
Platform length: 6 ft 0.8 in
Platform width: 2 ft 5.9 in
cylinders: 3,
displacement: 1.7 L,
horsepower: 49.6,
manufacturer: Kubota,
model: D1703-M-E3B,
type: Diesel
4-wheel drive: true,
hydraulic extending platform: true,
lcd control panel: true,
manual and automatic leveling: true,
rotating platform: false
Fuel tank capacity: 9.77 gal
Maximum slope: 30%
Outdoor use
Temperature range: -4°F to 122°F
Drive speed: 2.49 mph
Max platform height: 46.26 ft
Maximum horizontal reach: 24.11 ft
Maximum vertical reach: 29.97 ft
Maximum weight capacity: 992 lb
Working height: 52.99 ft
brakes: Hydraulic disc brakes,
number of speeds: Variable,
type: Hydraulic
Machine weight: 9,700 lb
Platform weight: 220 lb
